Orange LUMINOPHORE

Orange LUMINOPHORE
Orange single crystal phosphor material CIE (0.453; 0.530)

Luminescence properties



Emission centroid

[nm]

Maximum emission

[nm]

Max. of absorption

[nm]

Max abs. coefficient

[cm-1]

n @633nm [-]

Thermal conductivity

T= 25°C

[W.m-1 K-1]

Thermal conductivity

T= 100°C

[W.m-1 K-1]

Yellow/Orange

CIE (0.453; 0.530)

 588  555   460   ~60   1.83 7.7  5.4

Other Cryphosphor materials:

Green

CIE (0.326; 0.576)

545

510

450

~60

1.84

10.3

7.2

Yellow

CIE (0.418; 0.554)

573

535

459

~80

1.83

11.5

7.5

Yellow

CIE (0.434; 0.543)

580

545

460

~80

1.83

8.2

5.7
