Yellow LUMINOPHORE

Yellow LUMINOPHORE
Yellow single crystal phosphor material available in CIE (0.418; 0.554) and CIE (0.434; 0.543)

Luminescence properties





Emission centroid

[nm]

Maximum emission

[nm]

Max. of absorption

[nm]

Max abs. coefficient

[cm-1]

n @633nm [-]

Thermal conductivity

T= 25°C

[W.m-1 K-1]

Thermal conductivity

T= 100°C

[W.m-1 K-1]

Yellow

CIE (0.418; 0.554)

573   535  459  ~80  1.83  11.5  7.5

Yellow

CIE (0.434; 0.543)


580   545   460  ~80  1.83  8.2  5.7

Other Cryphosphor materials:

Green

CIE (0.326; 0.576)

545

510

450

~60

1.84

10.3

7.2

Yellow/Orange

CIE (0.453; 0.530)

 588  555 460   ~60  1.83   7.7 5.4
